iPhone 16 Pro Max vs iPhone 17 Pro Max
Short Description
iPhone 16 Pro Max
Screen size: 6.9" / Resolution: 1320 x 2868 px / Main camera: 48 MP & 48 MP & 12 MP / Front camera: 12MP / RAM: 8GB / Battery power: 4676 mAh / Has 5G support: ✔ / Internal storage: 128GB, 256GB, 512GB, 1TB / SIM cards: 1 SIM, 1 eSIM
iPhone 17 Pro Max
Screen size: 6.9" / Resolution: 1320 x 2868 px / Main camera: 48 MP & 48 MP & 48 MP / Front camera: 18MP / RAM: 12GB / Battery power: 4832 mAh / Has 5G support: ✔ / Internal storage: 256GB, 512GB, 1TB, 2TB / SIM cards: 1 SIM, 1 eSIM
Key Differences
iPhone 16 Pro Max
iPhone 17 Pro Max
How is iPhone 16 Pro Max better than iPhone 17 Pro Max?
Lighter: 227 g (8.01 ounces) vs 233 g (8.22 ounces)
Narrower: 77.6 mm (3.06 inches) vs 78 mm (3.07 inches)
Shorter: 163 mm (6.42 inches) vs 163.4 mm (6.43 inches)
More color options: Black Titanium, White Titanium, Natural Titanium, Desert Titanium vs Silver, Cosmic Orange, Deep Blue
iPhone 16 Pro Max
iPhone 17 Pro Max
How is iPhone 17 Pro Max better than iPhone 16 Pro Max?
Bigger battery capacity: 4832 mAh vs 4676 mAh
More RAM memory capacity in max option: 12GB vs 8GB
More internal storage in max option: 256GB, 512GB, 1TB, 2TB vs 128GB, 256GB, 512GB, 1TB
More megapixels front camera: 18MP vs 12MP
Higher charging speed: 40W vs 20W
The phone is 11 months newer
Size Comparison
iPhone 16 Pro Max
iPhone 17 Pro Max
Height
163 mm
(6.42 inches)
Width
77.6 mm
(3.06 inches)
Thickness
8.3 mm
(0.33 inches)
Screen size
6.9"
Weight
227 g
(8.01 ounces)
6.9"
6.9"
Height
163.4 mm
(6.43 inches)
Width
78 mm
(3.07 inches)
Thickness
8.75 mm
(0.34 inches)
Screen size
6.9"
Weight
233 g
(8.22 ounces)
Height
163 mm
(6.42 inches)
Width
77.6 mm
(3.06 inches)
Thickness
8.3 mm
(0.33 inches)
Screen size
6.9"
Weight
227 g
(8.01 ounces)
Height
163.4 mm
(6.43 inches)
Width
78 mm
(3.07 inches)
Thickness
8.75 mm
(0.34 inches)
Screen size
6.9"
Weight
233 g
(8.22 ounces)
Vote for Your option
iPhone 16 Pro Max
Vote for Your option
iPhone 17 Pro Max
Comparison videos
200,000+ views
iPhone 17 Pro Max Vs iPhone 16 Pro Max - REVIEW OF SPECS!
100,000+ views
10 SHOCKING LEAKS Between iPhone 17 Pro Max vs iPhone 16 Pro Max
70,000+ views
IPhone 16 Pro Max Vs IPhone 17 Pro Max
30,000+ views
iPhone 17 Pro Max VS iPhone 16 Pro Max
Technical Specifications
Show differences
Show differences
Specs
iPhone 16 Pro Max
iPhone 17 Pro Max
Design
Weight
227 g (8.01 ounces)
233 g (8.22 ounces)
Thickness
8.3 mm (0.33 inches)
8.75 mm (0.34 inches)
Width
77.6 mm (3.06 inches)
78 mm (3.07 inches)
Height
163 mm (6.42 inches)
163.4 mm (6.43 inches)
Is weather-sealed (splashproof)
✔
-
Ingress Protection (IP) rating
IP68
IP68
Waterproof depth rating
6 m
6 m
Volume
104.99 cm³
111.52 cm³
Is dustproof and water-resistant
✔
-
Color options
Black Titanium, White Titanium, Natural Titanium, Desert Titanium
Silver, Cosmic Orange, Deep Blue
Lowest potential operating temperature
0 °C
0 °C
Maximum operating temperature
35 °C
35 °C
Water resistance
-
Waterproof
Display
Screen size
6.9"
6.9"
Display type
OLED/AMOLED
OLED/AMOLED
Pixel density
460 ppi
460 ppi
Resolution
1320 x 2868 px
1320 x 2868 px
Refresh rate
120Hz
120Hz
Touch sampling rate
-
120Hz
Brightness (typical)
1600 nits
1000 nits
Has branded damage-resistant glass
✔
✔
Supports HDR10
✔
✔
Always-On Display
✔
✔
Supports Dolby Vision
✔
✔
Contrast ratio
2000000:1
2000000:1
Has a touch screen
✔
✔
Performance
Internal storage
128GB, 256GB, 512GB, 1TB
256GB, 512GB, 1TB, 2TB
RAM
8GB
12GB
CPU speed
2 x 3.89 GHz & 4 x 2.2 GHz
2 x 3.89 GHz & 4 x 2.2 GHz
GPU clock speed
1450 MHz
1490 MHz
Has integrated LTE
✔
✔
RAM speed
4800 MHz
-
Supports 64-bit
✔
-
Has integrated graphics
✔
-
Uses big.LITTLE technology
✔
-
CPU threads
6 threads
-
Uses HMP
✔
-
Has TrustZone
✔
-
Maximum memory bandwidth
78.8 GB/s
78.8 GB/s
DDR memory version
5
-
Maximum memory amount
8GB
-
Shading units
128
128
Release date
2024
2025
Has NX bit
✔
-
Cameras
Main camera
48 MP & 48 MP & 12 MP
48 MP & 48 MP & 48 MP
Front camera
12MP
18MP
Has built-in optical image stabilization
✔
✔
Video recording (main camera)
2160 x 60 fps
2160 x 120 fps
Wide aperture (main camera)
f/1.78 & f/2.2 & f/2.8
f/1.78 & f/2.2 & f/2.8
Has a dual-tone LED flash
✔
✔
Has a BSI sensor
✔
✔
Has continuous autofocus when recording movies
✔
✔
Has phase-detection autofocus for photos
✔
✔
Supports slow-motion video recording
✔
✔
Has a built-in HDR mode
✔
✔
Has a flash
✔
✔
Has manual exposure
✔
✔
Has a dual-lens (or multi-lens) main camera
✔
✔
Optical zoom
5x
8x
Number of flash LEDs
2
2
Has a CMOS sensor
✔
✔
Has manual ISO
✔
✔
Has a serial shot mode
✔
✔
Has manual focus
✔
✔
Has a front camera
✔
✔
Has laser autofocus
✔
✔
Has manual white balance
✔
✔
Shoots raw
✔
✔
Has touch autofocus
✔
✔
Has manual shutter speed
✔
✔
Can create panoramas in-camera
✔
✔
Wide aperture (front camera)
f/1.9
f/1.9
Has timelapse function
✔
✔
Supports Dolby Vision recording
✔
✔
Minimum focal length
13 mm
13 mm
Maximum focal length
120 mm
120 mm
Pixel size (main camera)
1.22 µm & 0.7 µm & 1.12 µm
1.22 µm & 0.7 µm & 1.12 µm
Supports HDR10 recording
-
✔
Operating system
Has clipboard warnings
✔
✔
Has location privacy options
✔
✔
Has camera/microphone privacy options
✔
✔
Has dark mode
✔
✔
Has Wi-Fi password sharing
✔
✔
Has battery health check
✔
✔
Has an extra dim mode
-
✔
Has focus modes
✔
✔
Can offload apps
✔
✔
Has customizable notifications
✔
✔
Supports instant markup
✔
-
Supports PiP and PaP
✔
-
More languages supported
56
-
Has sharing intents
✔
✔
Has a child lock
✔
✔
Supports widgets
✔
✔
Tracks the current position of a mobile device
✔
✔
Has Mail Privacy Protection
✔
✔
Can block app tracking
✔
✔
Blocks cross-site tracking
✔
✔
Has on-device machine learning
✔
✔
Has Live Text
✔
✔
Has SharePlay
✔
✔
Gets direct OS updates
✔
✔
Has AirPlay
✔
✔
Has Quick Start
✔
✔
Has offline voice recognition
✔
✔
The browser has word wrap
✔
-
Has voice commands
✔
✔
Has notification permissions
-
✔
Has media picker
-
✔
Has full-page screenshots
-
✔
Has PiP
-
✔
Battery
Battery power
4676 mAh
4832 mAh
Has wireless charging
✔
✔
Supports fast charging
✔
✔
Charging speed
20W
40W
Wireless charging speed
15W
30W
Has a battery level indicator
✔
✔
Has a rechargeable battery
✔
✔
Battery life
33 hours
39 hours
Audio
Has stereo speakers
✔
✔
Number of microphones
2
3
Features
Has 5G support
✔
✔
Wi-Fi version
Wi-Fi 6 (802.11ax), Wi-Fi 5 (802.11ac), Wi-Fi 4 (802.11n), Wi-Fi 6E (802.11ax), Wi-Fi 7 (802.11be)
Wi-Fi 6 (802.11ax), Wi-Fi 5 (802.11ac), Wi-Fi 4 (802.11n), Wi-Fi 6E (802.11ax), Wi-Fi 7 (802.11be)
Download speed
10000 MBits/s
10000 MBits/s
Upload speed
3500 MBits/s
3500 MBits/s
Has USB Type-C
✔
✔
USB version
3.2
3.2
Has NFC
✔
✔
SIM cards
1 SIM, 1 eSIM
1 SIM, 1 eSIM
Has emergency SOS via satellite
✔
✔
Bluetooth version
5.3
6
Has a gyroscope
✔
✔
Has GPS
✔
✔
Has a compass
✔
✔
Supports Wi-Fi
✔
✔
Has a cellular module
✔
✔
Has a barometer
✔
✔
Supports Galileo
✔
✔
Has an infrared sensor
✔
✔
Has an accelerometer
✔
✔
Has crash detection
✔
✔
Uses 3D facial recognition
✔
✔
Disclaimer! NFC, GSM network support, and some other specs can be different depending on the country.
